Recommended For: Low-medium pressure,petroleum based fluids or glycol-water based fluids at high pressure.Such as mineral oils, fuels, hydrocarbons.
Special Features: Working pressure exceeds EN857 1SC standard requirements. Good flexibility,lower bend radius.Suitable for complex high pressure hydraulic circuits. Validated for 300,000 impulse cycles.
Tube: Black, oil resistant, synthetic rubber.
Reinforcement: One braid of high-tensile steel wire.
Cover: Black, oilproof, Anti-abrasion&weather resistant, thin synthetic rubber
Working Temperature:-40℉to +212℉(-40℃to +100℃)
Wire braided reinforced hoses for low-medium pressure lines and return lines.High tensile steel braid.
Application:High pressure service with tight bends for petroleum or water-based hydraulic fluids.
Tube:High Temperature, High Impact synthetic rubber.
Reinforcement: One high tensile steel wire braid.
Cover:Abrasion and weather resistant synthetic rubber
Temp. Range:-40°C to+100°C.
