Wire braided reinforced hoses for low-medium pressure lines and return lines.High tensile steel braid.

Application:

High pressure hydraulic oil lines used in mobile,machine tool and agricultural application where higher temperature petroleum-or water based hydraulic fluids are a factor.

Tube:Nitrile.

Reinforcement: Two braids of high-tensile steel wire.

Cover:Black Neoprene Blend.

Temp. Range:-55°C to+100°C.

Applicable Standards:EN853 2SN,GB/T3683.1 2SN,SAE J517 R2S,ISO 1436 2SN
